20 CYCLONE & ATOM INSTRUCTION MANUAL
5. After the status LED is finished blinking, press and release
the 1-TOUCH button. This will select the next profile and
the LED will blink the appropriate number of times to
indicate which profile is selected.
NOTE: After profile 3 has been selected, the selection process
rolls over to profile 1.
6. Once you have selected the desired profile and the 1-Touch
button has not been pressed for approximately five
seconds, the speed control loads the selected profile into
memory, exits the profile selection mode, and the status
LED turns solid red. The selected profile is stored in a non-
volatile memory, which will remain stored after the speed
control’s power has been turned off.
CUSTOM PROFILE NOTE: The Cyclone & Atom are able to
access a fourth profile. This Custom Profile can only be created
with the Novak Pit Wizard or ESC Profile Software (connected
via the ESC’s Data Link
™ ). Once a customized profile has
been created and downloaded into the ESC, the throttle pro-
file selection will have a profile 4. You may access this profile
by following the same procedures in this step (if status LED
blinks red four times after the button is released, then the
Custom Profile is selected).
For further details refer to the Pit
Wizard or ESC Profile Software instruction manual.
Programmable parameters with the Novak Pit Wizard
(#1035) or ESC Profile Software (#1030) include:
• Neutral Position • Drag Brake Frequency*
• Full Throttle Position • Drive PWM Frequency*
• Full Brake Position • Brake PWM Frequency*
• Dead Band Value • Minimum Drive Value
• Drag Brake Value • Drag Brake Toggle (on/off)
*Adjustable from 122 Hz to 23,400 Hz
STEP 6: Throttle Profile Selection (continued)
Continued
