12. Install and tighten supplied acorn nut
using 11mm wrench.
13. Tighten #48 hose clamp at intake pipe
to inlet tube using 8mm Nut Driver.
14. Connect vent line to NEUSPEED intake
pipe.
15. AIR PUMP ONLY: Rotate air pump
fitting 90-degrees counter-clockwise.
16. AIR PUMP ONLY: Attach mini filter to
billet fitting and tighten. Then connect
to air pump hose fitting.
17. AIR PUMP ONLY: Attach supplied black
plastic hose support clip from radiator
coolant vent hose to air pump hose.
18. For extra protection, slide coolant hose
protector sleeve just under P-Flo
bracket.
19. Attach and tighten NEUSPEED air filter
using 8mm Nut Driver.
20. Install rubber strip on top-edge of P-Flo
bracket.
21. Double-check complete installation.
