Country implemented (all timing is in seconds and levels in dBm; see S99 register
descriptions) China and Taiwan are identical to USA, except for China transmit level.
U
SA
C
a
na
da
C
T
R
2
1
Fra
nc
e
U
K
It
a
ly
G
er
m
an
y
Jap
an
A
u
s
tr
a
li
a
Sp
a
in
A
ffe
c
te
d
re
gi
s
te
r
S99= 1 0 33 44 39 49 81 61 34 S99
Impedance 00 01 01 01 01 01 00 11 01 ACZ1:0
DC MASK 10 10 10 10 10 10 00 11 10 DAA1:0
Wait for blind dial time 2 4 2 4 4 4 4 4 4 S6
Billing_delay 2 2 2 2 2 2 2 2 2 S74
DTMF_speed 0.070 0.080 0.085 0.085 0.085 0.085 0.085 0.085 0.150 S11
Pulse dial make time 0.039 0.033 0.033 0.033 0.040 0.039 0.033 0.033 0.033 S32
Pulse dial break time 0.061 0.067 0.067 0.067 0.060 0.061 0.067 0.067 0.067 S33
Pulse dial interdigit
time
0.750 0.850 0.900 0.850 0.880 0.850 0.850 0.850 0.900 S34
Pulse dial map 0 0 0 0 0 0 0 0 0 S72
Imprecise dial tone
filter
280/68
0
240/580 370/500 240/580 370/500 240/580 240/580 240/580 240/580 S88
Imprecise Dial tone
detection level
-45 -42 -38 -38 -38 -38 -38 -38 -38 S75
Precise Dial tone
detection level
-45 -45 -40 -45 -40 -45 -45 -45 -40 S77
Dial tone type Imprecise Imprecise Imprecise Imprecise Imprecise Imprecise Imprecise Imprecise Imprecise S20
Dial tone precise freq.
350Hz selected
Sel. - Sel. - Sel. - - - Sel. S19
Dial tone precise freq.
440Hz selected
Sel. - - Sel. - Sel. Sel. Sel. - S19
Dial tone precise freq.
480Hz selected
- - Sel. - Sel. - - - - S19
Dial tone precise freq.
620Hz selected
- - - Sel. - - - - Sel. S19
Dialtone qualification
time
1.2 1.0 0.8 0.8 2.0 0.8 1.0 1.0 1.0 S67
Continuous Dial tone Yes Yes Yes Yes No Yes Yes Yes Yes S29
Cadenced Dial tone
Caden
ceA or
B
Double
cadenc
e
Cadence
A or B
Cadence
A or B
Double
cadence
Cadence
A or B
Cadence
A or B
Cadence
A or B
Cadence
A or B
S29
min_on_A_dt 0.000 0.160 0.000 0.000 0.160 0.000 0.000 0.000 0.800 S35
Max_on_A_dt 0.000 0.240 0.000 0.000 0.240 0.000 0.000 0.000 1.200 S36
min_off_A_dt 0.000 0.160 0.000 0.000 0.160 0.000 0.000 0.000 0.080 S37
Max_off_A_dt 0.000 0.240 0.000 0.000 0.240 0.000 0.000 0.000 0.120 S38
min_on_B_dt 0.000 0.480 0.000 0.000 0.480 0.000 0.000 0.000 0.240 S39
