Maxim Integrated Teridian V.22 bis Linux Softmodem for 73M1822/73M1922 MicroDAA User Manual
Page 17
UG_1x22_043
V.22 bis Linux Softmodem for 73M1x22 MicroDAA User Guide
Rev. 1.5
17
X
Result Codes Set and Dialing Capabilities Selection
X0
Enable Result Codes 0-4, 14
X1
Enable Result Codes 0-5, 10-14
X2
Enable Result Codes 0-6, 10-14
X3
Enable Result Codes 0-5, 7, 10-14
X4
Enable Result Codes 0-7, 10-14
X5
Enable Result Codes 0-5, 10-14 and detect BUSY at OFF HOOK
X6
Enable Result Codes 0-6, 10-14 and detect BUSY at OFF HOOK
X7
Enable Result Codes 0-5, 7, 10-14 and detect BUSY at OFF HOOK
X8
Enable Result Codes 0-7, 10-14 and detect BUSY at OFF HOOK
See Result Codes table under W command.
Pre Dial
Post Dial
W0
W1
W2
W0
W1
W2
X0
0, 2 – 4, 14
0, 2 – 4, 14
0, 2 – 4, 14
0 – 1, 3 – 4,
14
0–1, 3–4, 14 0–1, 3–4, 14
X1
0, 2 – 4, 14
0, 2 – 4, 14
+ ext.
0, 2 – 4, 14
0 – 1, 3 – 5,
9 – 14, 22, 23
0–1, 3–5,
9–14, 22, 23
+ ext.
0–1, 3–5,
9-14, 22, 23
X2
0, 2, 4, 6, 14 0, 2, 4, 6, 14 +
ext.
0, 2, 4, 6, 14 0 – 1, 3 – 5,
9 - 14, 22, 23
0–1, 3–5,
9–14, 22, 23
+ ext.
0–1, 3–5,
9-14, 22, 23
X3
0, 2 – 4, 14
0, 2 – 4, 14
+ ext.
0, 2 – 4, 14 0 – 1, 3 – 5, 7,
9 - 14, 22, 23
0–1, 3–5, 7,
9–14, 22, 23
+ ext.
0–1, 3–5, 7, 9-
4, 22, 23
X4
0, 2, 4, 6, 14 0, 2, 4, 6, 14 +
ext.
0, 2, 4, 6, 14 0 – 1, 3 – 5, 7,
9 - 14, 22, 23
0–1, 3–5, 7,
9–14, 22, 23
+ ext.
0–1, 3–5, 7,
9–14, 22, 23
X5
0, 2 – 4, 7, 14 0, 2 – 4, 7, 14
+ ext.
0, 2 – 4, 7, 14 0 – 1, 3 – 5,
9 - 14, 22, 23
0–1, 3–5, 9–
14, 22, 23
+ ext.
0–1, 3–5,
9-14, 22, 23
X6
0, 2, 4, 6 - 7,
14
0, 2, 4, 6 - 7,
14 + ext.
0, 2, 4, 6 - 7,
14
0 – 1, 3 – 5,
9 - 14, 22, 23
0–1, 3–5, 9–
14, 22, 23
+ ext.
0–1, 3–5,
9-14, 22, 23
X7
0, 2 – 4, 7, 14 0, 2 – 4, 7, 14
+ ext.
0, 2 – 4, 7, 14 0 – 1, 3 – 5, 7,
9 - 14, 22, 23
0–1, 3–5, 7,
9–14, 22, 23
+ ext.
0–1, 3–5, 7, 9-
14, 22, 23
X8
0, 2, 4, 6 - 7,
14
0, 2, 4, 6 - 7,
14 + ext.
0, 2, 4, 6 - 7,
14
0 – 1, 3 – 5, 7,
9 - 14, 22, 23
0–1, 3–5, 7,
9–14, 22, 23
+ ext.
0–1, 3–5, 7, 9-
14, 22, 23
