V.22 bis Linux Softmodem for 73M1x22 MicroDAA User Guide UG_1x22_043
16 Rev. 1.5
W Extended Result Codes Selection

W0 Do not return extended result codes (40-80). The message CONNECT followed
by the data rate between the DTE and the modem will be sent to the DTE
W1 The CONNECT message will report the DTE speed then enable the carrier and
extended result codes
W2 The CONNECT message will report the DCE speed. All extended result codes
are disabled
Result codes
Numeric
value
Verbose
value
Numeric
value
Verbose
value
0 OK 13 CONNECT 7200
1 CONNECT 14 LINE-IN-USE
2 RING 22 CONNECT 75/1200
3 NO CARRIER 23 CONNECT 1200/75
4 ERROR Extended Results Codes:
5 CONNECT 1200 40 CARRIER 300
6 NO DIALTONE 41 CARRIER 600
7 BUSY 44 CARRIER 1200/75
8 NO ANSWER 45 CARRIER 75/1200
9 CONNECT 600 46 CARRIER 1200
10 CONNECT 2400 47 CARRIER 2400
11 CONNECT 4800 70 PROTOCOL:NONE
12 CONNECT 9600 77 PROTOCOL:LAP-M
