UG_1x22_043 V.22 bis Linux Softmodem for 73M1x22 MicroDAA User Guide
Rev. 1.5 21
2.2.1.1 TR30.2-Style Control and Status Registers
S0 Auto Answer
n 0 –255
 0 Auto answer disabled
1-255 Auto answer mode on selected number of rings
This register specifies the ring on which the modem will answer. A value of 1 to 255 will
place the modem in auto-answer mode and cause it to answer on that many rings
detected.
S1 Ring Count
n 0 –255
 0 No valid rings detected
When the modem is set for Auto-Answer, register S1 keeps track of the number of times
the phone rings. After the end of ring-on time, the S1 register is reset to 0 after the sum of
S56 and S58 seconds has elapsed.
S2 Escape Code Character
n 0 – 127 (ASCII)
 43 ASCII “+”
>127 Escape feature disabled
S3 Carriage Return Character
n 0 – 127 (ASCII)
 13
This character terminates both the command line and the result codes.
