KGUARD Security EL1622 - Manual (Page 104)

ENGLISH
Easy Link PRO Series: Appendix
104
DVR User’s Manual
Model No. EL-422 EL-822 EL-1622
Local Playback
Max. 4 Channels
Simultaneously
Max. 8 Channels Simul-
taneously
Max. 16 Channels
Simultaneously
Playback Search Date & Time / Event List / Time Bar
Playback Mode Play, Fast Forward, Fast Rewind, Slow Motion, Zoom
General
PTZ Control
RS485 Built-In, supports PELCO-P & PELCO-D
Sensor & Alarm I/O Port No Yes
IR Extender Port No Yes
Backup Method HDD, USB, Network
Power Supply 12V/2A
Operating Temperature (W/O HDD) -10° to 50° ( 14°F to 122°F )
Storage Temperature -20° to 70° ( -4°F to 158°F )
Working Humidity 10%~90%
Dimension (LxWxH) in mm 250 x 230 x 45 300 x 220 x 50
1. Trademarks are properties of their respective owners.
2. Specifications are subject to change without notice.
