Device layout – Samsung Galaxy Note Edge User Manual
Page 8
Getting started
8
Device layout
Microphone
Back key
Multipurpose jack
Power key
Front camera
Proximity/Light/Gesture
sensor
Edge screen
Touchscreen
Recents key
Microphone
Home key (Fingerprint
recognition sensor)
LED indicator
Receiver
Headset jack
Infrared port
Microphone
Volume key
NFC antenna (on the
battery)
Rear camera
GPS antenna
Flash
Back cover
Loud speaker
Main antenna
S Pen
