Isys ® G-Series Touchpanel Interface Crestron TPS-GA-TPI
(Tools | Network Device Tree) to show all network devices connected to the control
system. Right-click on the TPS-GA-TPI to display actions that can be performed on
the TPS-GA-TPI.
Ethernet Connections For Ethernet connections, display the “System Info window (click the
icon) and
select the Functions menu to display actions that can be performed on the
TPS-GA-TPI.
Be sure to use the Crestron Toolbox to create the TPS-GA-TPI IP table.
• Select Functions | IP Table Setup.
• Add, modify or delete entries in the IP table. The TPS-GA-TPI can have
only one IP table entry.
• A defined IP table can be saved to a file or sent to the device.
Edit the control system’s IP table to include an entry for the TPS-GA-TPI. The entry
should list the TPS-GA-TPI’s IP ID (specified on the TPS-GA-TPI’s IP table) and
the internal gateway IP address 127.0.0.1.
44 • Isys ® G-Series Touchpanel Interface: TPS-GA-TPI Operations Guide – DOC. 6609A
