Crestron TPS-GA-TPI Isys ® G-Series Touchpanel Interface
Video Setup
The TPS-GA-TPI can display two fully scalable and movable, full motion video
windows, each supporting standard video, HDTV and high-resolution RGB signals
from external AV and computer sources. These units use auto-detect for composite,
S-video, component or RGBHV. They support SDTV (NTSC and PAL), EDTV,
HDTV and RGB (VGA) up to UXGA (1600 x 1200). Two video inputs provide
signals that can be displayed on the QM output.
A table describing the video menu controls follows the illustrations. Touching the
Video button on the SETUP MENU, will open the screen shown below. From here,
you can enter the setup screens for both Video 1 and Video 2 by touching their
respective buttons.
VIDEO SETUP
Refer to the table on the following page for additional VIDEO SETUP menu details.
Operations Guide – DOC. 6609A Isys ® G-Series Touchpanel Interface: TPS-GA-TPI • 25
