Crestron TPS-GA-TPI Isys ® G-Series Touchpanel Interface
GENERAL AUDIO SETUP MENU
Refer to the following table for additional GENERAL AUDIO SETUP menu details.
General Audio Setup Details
GENERAL
AUDIO SETUP
SCREEN
CONTROLS
DESCRIPTION
QM Output Displays the QM AUDIO OUTPUT SETUP menu.
Play Test WAV
File Plays a short WAV audio file.
Restore Default
Audio Settings Returns the audio settings to their factory defaults.
Mute A separate Mute button is supplied for each of the
volume controls.
Key Click Volume Adjusts the level of the key click sound with the - and +
buttons.
WAV Volume Adjusts the volume of the WAV file with the - and +
buttons. Click Play Test WAV File button to sample and
adjust the volume as a pre-loaded WAV file plays.
Headphone
Volume Adjusts the level of the headphones with the - and +
buttons. (This control is visible only when headphones
are connected.)
Bass Adjusts the overall bass output with the - and + buttons.
Treble Adjusts the overall treble output with the - and + buttons.
Headphone
Balance Adjusts the overall left/right balance of the headphone
output with the - and + buttons. (This control is visible
only when headphones are connected.)
Operations Guide – DOC. 6609A Isys ® G-Series Touchpanel Interface: TPS-GA-TPI • 23
