English
FEATURES
1. Five 2-channeI modes
• 48 kHz mode: Sampling frequency of 48 kHz, 16-bit linear
quantization
• 44 kHz mode: Sampling frequency of 44.1 kHz, 16-bit
linear quantization
• 32 kHz mode: Sampling frequency of 32 kHz, 16-bit linear
quantization
• 32 kHz LP (Long Play) mode: Sampling frequency of
32 kHz, 12-bit non-linear quantization
• 44 kHz WT (Wide Track, playback only) mode: Sampling
frequency of 44.1 kHz, 16-bit linear quantization
2. SCMS (Serial Copy Management System)
• Only one digital recording can be made of CD software
3. High-precision fine-tracking digital servo mechanism
• Philips's high-precision mechanism makes possible the
LP (Long Play) mode
4. Fourth-order delta sigma type 1-bit ADC (Analog to
Digital Converter)
5. 1-bit DAC (PEM DD converter)
6. AUTO ID EDIT function
• The optimum START ID position is automatically shown
in the display
7. Sampling monitor facility
8. 20-dot digital meter (with peak hold function)
• The digital peak display shows the margin
9. Tray type cassette loading
10. Direct access playback with 10-key remote control
11. Separate sub code keys
(with Renumber function)
12.10-key wireless remote control
13. Digital input/output terminals (Coaxial/Optical)
• Meeting digital audio interface standards
14. SOURCE selector (Digital/Analog)
REMOTE CONTROL SYSTEM
This is a convenient system which has been originated and
developed by Philips. Before starting operation, connect the
remote cable as shown on page 7. The followings are the
brief explanation of its major performances:
Synchronized Recording
Synchronized recording refers to the process in which the
DAT deck starts recording in synchronism with the CD player.
Please study these instructions carefully before starting to
operate the unit, to use the unit correctly. We take no responsibility
for any problems resulting from misuse of this unit if it is operated,
by methods other than those given in this manual.
On operating this unit:
Since this unit incorporates a microprocessor which controls
various functions, please read the description and cautions
(notes) for each item carefully before use.
If operated incorrectly, the required functions may not be per­
formed. In this case, turn the power OFF then turn it ON again
and see if correct operation has become possible.
• Types of DAT cassettes
Mode Maximum recording time
Cassette 48k/44k/32k mode 32k-LP mode
R-120 2 hours 4 hours
R-90 1 h.30 min. 3 hours
R-60 1 hour 2 hours
R-46 46 minutes 1 h.32 min.
Notes:
1. Cassettes recorded in the 32k-LP mode by this unit cannot
be played back using DAT decks exclusively for the 48k or
32k mode.
The 44k-WT mode is used only when DAT prerecorded tapes
made from master tapes by the contact printing process are
played.
2. DAT: abbreviation of Digital Audio Tape
LP: abbreviation of Long play
WT: abbreviation of Wide track
Important note for users in U.K.:
The U.K. version is not fitted with a mains plug.
When fitting a mains plug to the mains lead note that the
wires in the mains lead are coloured with the following code:
Blue = Neutral, Brown = Live.
As these colours may not correspond with the colour mark­
ings identifying theterminals in your plug proceed as follows:
the Brown wire must be connected to the terminal which is
marked with the letter L or coloured Red.
The Blue wire must be connected to the terminal which is
marked with the letter N or coloured Black.
Note: This apparatus must be protected by a 3 Amp Fuse if a
13 Amp plug is used or, if any other type of plug is used, by
a 5 Amp Fuse either in the plug or adapter or atthe distribution
board. If in doubt consult a qualified electrician.
DO NOT CONNECT EITHER WIRE TO THE EARTH TERMINAL
IN THE PLUG WHICH IS MARKED BY THE LETTER E OR BY
THE SAFETY EARTH SYMBOL OR COLOURED GREEN OR
GREEN-AND-YELLOW
