0BChapter 1: Camera operation
6 TruVision IP Camera Configuration Manual
If there is more than one camera connected over the network, open a separate
web browser window for each individual camera.
Figure 1: Web browser interface
Table 1: Overview of the web browser interface
Item Name Description
1. Live view Click to view live video.
2. Playback Click to play back video.
3. Log Click to search for event logs. There are three main types:
Alarm, Exception and Operation.
4. Configuration Click to display the configuration window for setting up the
camera.
5. Current user Displays current user logged on.
6. Logout Click to log out from the system. This can be done at
anytime.
7. PTZ controls Direction actions, zoom, focus, iris, light and wiper control.
Note: Direction actions, lighter and wiper control can be
used if the camera supports RS-485 and external pan/tilt
unit, light or wiper is installed.
8. Viewer View live video. Time, date and camera name are displayed
here.
9. Start/stop live view Click to start/stop live view.
10. Capture Click to take a snapshot of the video. The snapshot will be
saved to the default folder in JPEG format.
11. Start/stop recording Click to record live video.
12. Digital Zoom Click to enable digital zoom.
