1BChapter 2: Camera operation
12 TruVision IP Camera Configuration Manual
Configuring network settings
Accessing the camera through a network requires that you define certain network
settings. Use the “Network” folder to define the network settings. See Figure 5
and Table 4 below for further information.
Figure 5: Network window (TCP/IP subfolder shown)
Table 4: Network parameters
Parameters Description
TCP/IP NIC Type: Specifies the NIC type. Default is 10M/100M Auto. Other options
include: 10M Half-dup, 10M Full-dup, 100M Half-dup and 100M Full-dup.
IPv4 Address: Specifies the IP address of the camera.
IPv4 Subnet Mask: Specifies the subnet mask.
IPv4 Default Gateway: Specifies the gateway IP address.
DHCP: Enable to automatically obtain an IP address and other network
settings from that server.
MTU: The valid value range of MTU is 500 to 9676. Default is 1500.
Multicast Address: Specifies a D-class IP address between 224.0.0.0 to
239.255.255.255. Only specify this option if you are using the multicast
function. Some routers prohibit the use of multicast function in case of a
network storm.
DNS server: Specifies the DNS server for your network.
Port HTTP Port: Specifies the port used for the Internet Explorer (IE) browser.
Default value is 80.
RTSP Port: Specifies the RTSP port. The default port number is 554.
HTTPS Port:
Specifies the HTTPS port. The default port number is 443.
DDNS Specifies IP server, DynDNS
PPPoE Use this option to retrieve a dynamic IP address.
