32
Simon XT Installation Manual
Control
Description
Disarm
Press to turn off intrusion/burglary protection for your system. Only
intrusion/burglary sensors such as doors, windows, and motion
sensors are disarmed. Environmental sensors, such as smoke and
carbon monoxide, stay active at all times.
Status
Press to determine system status.
Silent
Press to silence exit beeps when arming.
Bypass
Press to bypass a sensor.
Emergency (cross)
Press and hold the Emergency button for two seconds (or press twice
quickly) to call the central monitoring station and notify them of a
nonmedical call for help.
Police (shield)
Press and hold the Police button for two seconds (or press twice
quickly) to call the central monitoring station and notify them of a
nonmedical call for help.
Fire (flame)
Press and hold the Fire button for two seconds (or press twice quickly)
to call the central monitoring station and notify them of a nonmedical
call for help.
Microphone
Used to communicate with the central monitoring station after an
alarm.
Scroll up/scroll down
Press to scroll through lists of similar items.
OK
Press to select a particular menu item or commit to memory a menu
item that has just been programmed.
Numeric keypad
Twelve-key telephone-type keypad (0 through 9, *, #) for entering
access codes or other numerical data.
* (light bulb)
Lights on. (Contact UTC Fire & Security for required equipment
information.)
# (dark light bulb)
Lights off. (Contact UTC Fire & Security for required equipment
information.)
Speaker #
Provides voice output and sounds key beeps. The panel speaks
arming level change, system status, and voice chime sensor trips. The
panel voice is also used for voice reporting and remote phone control.
Door
Covers the lower panel.
Entering and exiting the system menu
To enter the system menu, press either the scroll up/down or enter buttons in the
upper right of the panel.
Press the STATUS button to exit a menu or option edit mode and navigate up
one level. Pressing the STATUS button while in the top menu level exits the
system menu level. The panel automatically exits the system menu after a few
seconds of inactivity if no access code has been entered yet. After an access
code has been entered to access a code-protected area of the system menu, the
timeout is 4 minutes.
