DIP Switch Setup
Before you install the camera, you should set the DIP switches to configure the camera ID, communication
protocol.
ON ON
PR
OT0
ID0
1 8 1 8
PR
OT1
PR
OT
2
ST
0
ST
1
ST
2
ST
3
ID7
CAM ID
Communication
Protocol
Camera ID
‰ Camera ID Setup
1 2 3 4 5 6
ON
ON
7 8
z ID number of camera is set using binary number. The example is
shown bellow.
Pin 1 2 3 4 5 6 7 8
ID Value 1 2 4 8 16 32 64 128
ex) ID=5 on off on off off off off off
ex) ID=10 off on off on off off off off
z The range of ID is 1~255. Do not use 0 as camera ID. Factory
default of Camera ID is 1.
z If you want to control a certain camera, you must match the camera
ID with Cam ID setting of DVR or Controller.
