Speed Dome Camera Instruction Manual

19/47

Pattern

Function

Pattern Function is that a camera memorizes the path (mostly curve path) by joystick of
controller for assigned time and revives the path exactly as it memorized.

4 Patterns are available and Maximum 1200 communication commands can be stored in
a pattern.

Set Pattern

Pattern can be created by one of following two methods.

Method 1) [Pattern NO.]

{

Pattern editing screen is displayed as bellow.

EDIT PATTERN 1

[NEAR:SAVE /FAR:DELETE]
0/0/x1/N

{

Movement by Joystick and preset movement can be memorized in a pattern.

{

The rest memory size is displayed in progress bar.

{

To save the recording, press NEAR key and to cancel, press FAR key.

Method 2) OSD Using OSD Menu: See the section “How to use OSD Menu”.

Run Pattern

Method 1) [Pattern NO.]

Method 2) [Pattern NO.+130]

ex) Run Pattern 2 : [2]

ex) Run Pattern 2: [132]

Delete Pattern

Use OSD menu to delete a Pattern.

OPERATION
