Speed Dome Camera Instruction Manual 30/47
‰ White Balance Setup
WB SETUP - GLOBAL
------------------------
WB MODE AUTO
RED ADJUST ---
BLUE ADJUST ---
BACK
EXIT
‰
Auto Exposure Setup
AE SETUP - GLOBAL
------------------------
BACKLIGHT OFF
DAY/NIGHT AUTO
SLOW SHUTTER OFF
AE MODE AUTO
IRIS LEVEL ---
GAIN LEVEL ---
SHUTTER SPD ---
BRIGHTNESS 50
BACK
EXIT
z WB Mode [AUTO/MANUAL]
In Manual mode, Red and Blue level can be set
up manually
z Red Adjust [0~255]
z Blue Adjust [0~255]
z Backlight [OFF/C1/C2/L1/L2/U1/U2/D1/D2/R1/R2]
Selects the criteria area in image and decide
the Backlight level. Refer to the following table.
z Day/Night [AUTO/DAY/NIGHT]
z Slow Shutter [OFF, 2~128 Field]
Sets Digital Slow Shutter. The number of piled
field can be setup.
z AE Mode [AUTO/SHUTTER/IRIS/MANUAL]
Sets AE(Auto Exposure) mode.
Only if Day/Night mode is set to Day or Night
and Slow Shutter mode is set to OFF, AE can be
set.
z IRIS Level [0~255]
If AE mode is set to IRIS mode or Manual mode,
this can be set up.
z GAIN Level [0~255]
If AE mode is set to Manual mode, this can be
set up.
z Shutter Speed [0~27]
If AE mode is set to Shutter Speed mode or
Manual mode, this can be set up.
Refer to the following table for the value in
correspondence with Shutter Speed.
z Brightness [0~96]
If AE mode is not set to Manual mode, this can
be set up.
HOW TO USE OSD MENU
