How to use osd menu – IC Realtime 22X Optical / 10X Digital Zoom High Res Day/Night Speed Dome-24VAC (ICR2200DN) User Manual
Page 35
Speed Dome Camera Instruction Manual
35/47
Parking Action Setup
PARKING ACTION SETUP
------------------------
PARK ENABLE OFF
WAIT TIME 00:10:00
PARK ACTION HOME
BACK
EXIT
Alarm Input Setup
ALARM ACTION SETUP
------------------------
ALARM 1 ACT NOT USED
ALARM 2 ACT NOT USED
ALARM 3 ACT NOT USED
ALARM 4 ACT NOT USED
BACK
EXIT
If Park Enable is set to ON, camera runs assigned function automatically
if there is no PTZ command during assigned "Wait Time".
z
Park Enable
[ON/OFF]
z
Wait Time
[1 minute ~ 4 hour]
The time is displayed with "hh:mm:ss" format
and you can change this by 1 min unit.
z
Park Action
[HOME/PRESET/PATTERN/SWING/GROUP]
{
HOME
Camera moves to home position if there is no
PTZ command during assigned "Wait Time".
Match the Alarm sensor input to one of Preset positions. If an external
sensor is activated, camera will move to corresponding preset position
when this item is predefined.
z
Alarm × Action
[NOT USED/PRESET 1~128]
Assign counteraction Preset position to each
Alarm input.
