Speed Dome Camera Instruction Manual 5/47
Features
‰ Camera Specifications
z CCD Sensor : 1/4" SONY Super HAD CCD → Ч22, Ч30 Model
1/4" SONY EXView CCD → ×26 Model
z Zoom Magnification : × 22 Optical Zoom, × 10 Digital Zoom (Max × 220 Zoom) → ×22 Model
× 30 Optical Zoom, × 10 Digital Zoom (Max × 300 Zoom) → ×30 Model
× 26 Optical Zoom, × 12 Digital Zoom (Max × 312 Zoom) → ×26 Model
z Day & Night Function
z Various Focus Mode : Auto-Focus / Manual Focus / Semi-Auto Focus.
z Independent & Simultaneous Camera Characteristic Setup in Preset operation
‰ Powerful Pan/Tilt Functions
z Max. 360°/sec high speed Pan/Tilt Motion
z Using Vector Drive Technology, Pan/Tilt motions are accomplished in a shortest path. As a result,
time to target view is reduced dramatically and the video on the monitor is very natural to watch.
z For jog operation using a controller, since ultra slow speed 0.05°/sec can be reached, it is very easy
to locate camera to desired target view. Additionally it is easy to move camera to a desired position
with zoom-proportional pan/tilt movement.
‰ Preset, Pattern, Swing, Group, Privacy Mask and More…
z MAX. 127 Presets are assignable and characteristics of each preset can be set up independently,
such as White Balance, Auto Exposure, Label, Digital Outputs and so on.
z Max. 8 set of Swing action can be stored. This enables to move camera repetitively between two
preset positions with designated speed.
z Max. 4 of Patterns can be recorded and played back. This enables to move camera to follow any
trajectory operated by joystick as closely as possible.
z Max. 8 set of Group action can be stored. This enables to move camera repetitively with
combination of Preset or Pattern or Swing. A Group is composed of max. 20 entities of
Preset/Pattern/Swings.
z Privacy Masks are assignable, not to intrude on other’s privacy. (8 Privacy Zones)
→ The availability for Privacy Mask function should be different by models.
‰ PTZ(Pan/Tilt/Zoom) Control
z With RS-485 communication, max. 255 of cameras can be controlled at the same time.
z Pelco-D or Pelco-P protocol can be selected as a control protocol in the current version of firmware.
INTRODUCTION
1
