GTCO SummaSketch FX - Users Guide User Manual
Page 2
SummaSketch FX 2
Part I: Installing and Using the Tablet
Chapter 1: Preparing for Use
Unpacking the Equipment
The SummaSketch FX package contains the following equipment:
Tablet with clear plastic overlay
Convertible transducer with batteries for cordless operation and cable for corded
operation
PC-compatible interface cable
25-to-9 pin serial adapter cable
Power supply
Drivers/utilities software
User’s manual
If anything is missing from the package, contact your authorized dealer or GTCO CalComp
by Turning Technologies at 1.866.746.3015 or
Connecting the Hardware
Follow the below steps to installing the SummaSketch FX tablet.
1. Connect the SummaSketch FX to the computer. Plug the phone-type connector of
the interface cable into the tablet’s top left marked.
