• DS-EQ230 Menu and Sub-Menu Structures
As stated above, the start-up default screen is the following factory preset:
From this point, sub-menus are accessed using the “UTILITY”, “LOUT/ROUT”, “LCOMP/RCOMP”,
“ENTER” and “ESC” buttons and all parameters and values are navigated by the “NAV/PM1”,
“PM2” and “PM3” encoders. Please refer to the following menu structures:
DS-EQ230
Default Flat
• Menu "UTILITY" [access by pushing the "UTILITY" button]
From the “Default Screen”, it is possible access the “UTILITY” menu pushing the “UTILITY” button
and the Sub-Menus pages can be selected just rotating clockwise and counter-clockwise the
“NAV/PM1” encoder.
Once selected the sub-menu page, using the “ENTER” button can be accessed the Sub-Menus
pages, again “scrollable” using the “NAV/PM1” encoder and accessible for the parameters’ editing
pushing again the “ENTER” button.
Through the “ESC” button, it is any time possible to go back to the action and page preceding the
“ENTER” button use.
Once inside the Sub-Menus pages, the several options can be scrolled and using the “PM2” or
“PM3” encoders and selected/confirmed pushing the “ENTER” button.
Note: In every Sub-Menu the option currently selected/running will have an asterisk “*” showing to
the right of the description on the LCD screen
.
Options that are not selected/running will be displayed with NO Asterisk.
Pushing the ENTER button on an unselected option will mean an asterisk will then appear and this
option will now take over as the currently selected/running option.
System Utilities Sub-menu - this sub-menu allows to access several operations related to the
DS-EQ230 Start Up and General Configuration:
UTILITY MENU
- System Utilities -
