Delay page - from this page it is possible to set the Equalizer’s Channels Delay Time from
000.000mS up to 848.9984mS, by steps of 1mS or 20.8uS.
To set the Delay time press ENTER an arrow will appear on the left of the screen “->”. Then use
the “PM2” encoder to set the Delay Time in steps of 1mS and the “PM3”, for setting the “fine” Delay
Time in steps of 20.8 microseconds.
The following is an example screen for the “Delay” page where the Delay Time of Equalizer’s
Channel A (named Left) is set to 160.1872mS:
HPF sub-menu - from this sub-menu it is possible to set the Equalizer’s Channels High Pass Filter
(HPF).
The following is an example of a HPF sub-menu screen with the filter set at 24dB Linkwitz/Riley on
Equalizer’s Channel A (named Left):
The filter’s parameters can be modified by use the “PM2” and “PM3” encoders for editing the
Filter’s Low Cut Frequency and the Filter’s Type and Order.
The Low Cut Frequency of the High Pass Filter can be edited using the “PM2” encoder and the
Filter’s Type and Order can be edited by using the “PM3” encoder.
“Low Cut Frequency”: the selectable frequencies range is from 20Hz to 20kHz in steps of 1/24 of
an Octave and can be adjusted by rotating the “PM2” encoder.
“High Pass Type and Order”: allows you to select the Equalizer’s High Pass Filter Shape and
Order.
The available shapes and orders for the High Pass Filter, that are accessible by rotating the “PM3”
encoder, are listed below:
- No Cut-Off (High Pass Filter Bypassed)
- Butwrth 6dB (Butterworth Filter 6dB/Oct Slope)
- Butwrth 12dB (Butterworth Filter 12dB/Oct Slope)
- Lnk/Ril 12dB (Linkwitz/Riley Filter 12dB/Oct Slope)
- Bessel 12dB (Bessel Filter 12dB/Oct Slope)
- Butwrth l8dB (Butterworth Filter 18dB/Oct Slope)
- Butwrth 24dB (Butterworth Filter 24dB/Oct Slope)
- Lnk/Ril 24dB (Linkwitz/Riley Filter 24dB/Oct Slope)
- Bessel 24dB (Bessel Filter 24dB/Oct Slope)
Note1: Once the desired options have been selected using the 2 encoders, they are automatically
saved as current and stored in the DS-EQ230 system status once leaving the page.
Note2: To exit this page, push the “ESC” button.
DPA-240A
1x2 WAY X-OVER
DPA-240A
1x2 WAY X-OVER
OutputA Left Delay
-> Delay = 160.1872mS
OutputA Left HPF
-> 20.0 Hz Lnk/Ril 24dB
