Galaxy Audio DS-EQ230 - Manual (Page 15)

Security Sub-menu - this sub-menu allows the User to set the parameters shown, lock the
DS-EQ230 and set a Password, therefore limiting the unit's functions and controls to those who
have only access to the appropriate Password.
Press ENTER and then use the “NAV/PM1” to scroll between options.
Show Parameter: Pressing ENTER from the above menu will access the “Show Parameter” Sub
Menu.
Press ENTER again and use the “PM2” or “PM3” encoders to scroll between the “be shown” and
“not be shown” options. An asterisk will highlight which option is selected.
Choosing the “be shown” option means that once the unit is locked, you cannot access parameter
editing features, but they will be displayed on the LCD screen.
Choosing the “not be shown” option means that once the unit is locked, the parameters will
not be shown at all. With this option, when trying to access a parameter, the following screen
message will appear:
Lock Unit: this sub-menu allows the user to lock the device so no parameters can be edited or
modified.
When the Unit is in an unlocked condition, all parameters will be available for editing. When you
select On, all parameters will be locked and are not available for editing.
When you select lock from the menu, the unit will be locked and the lock menu automatically
exited. The screen will revert to the “Default” showing the current Equalizer’s preset selected and
beside the preset’s name a “keylock” icon indicating that the DS-EQ230 is locked.
DPA-240A
1x2 WAY X-OVER
DPA-240A
1x2 WAY X-OVER
DPA-240A
1x2 WAY X-OVER
DPA-240A
1x2 WAY X-OVER
DPA-240A
1x2 WAY X-OVER
DPA-240A
1x2 WAY X-OVER
Parameter will
Not be shown *
DPA-240A
1x2 WAY X-OVER
DPA-240A
1x2 WAY X-OVER
Lock Unit
Lock : On *
UTILITY MENU
- Security Utilities -
DPA-240A
1x2 WAY X-OVER
SECURITY UTILITY
- Show Parameter -
DPA-240A
1x2 WAY X-OVER
DPA-240A
1x2 WAY X-OVER
SECURITY UTILITY
- Lock Unit -
14
