Once loaded, the DS-EQ230 will exit to the “Recall a Program” screen automatically and the above
screen will disappear:
Note: At any time it is possible to quit the recalling action by pressing the “ESC” button.
Save a Program: this page allows you to store a new preset in the DS-EQ230’s memory:
By pressing the ENTER button and rotating the “PM2” or “PM3” encoder, it is possible to scroll
through the previously saved presets and the available empty locations (identified by “Empty
Memory”).
If no user presets are stored, the “Save a Program” screen will show empty memory locations for
all 09-32 presets as shown in the example below for location 10:
When storing an edited configuration for the DS-EQ230, select the location for a preset from the 24
available by using the “PM2” or “PM3” encoders.
Once the desired location appears on the screen press ENTER again to reach the “Set Program
Name” page.
In this page the User can enter a Preset Name (up to 16 Characters) by using the “PM2” or
“PM3” encoder to choose a character and the “NAV/PM1” encoder to move between the 16
available locations for the character’s positioning.
The current position of the cursor is shown by a “blinking underscore”.
DPA-240A
1x2 WAY X-OVER
DPA-240A
1x2 WAY X-OVER
Save a Program
10: Empty Memory
PROGRAM UTILITY
- Recall a Program -
DPA-240A
1x2 WAY X-OVER
PROGRAM UTILITY
- Save a Program -
The following is an example of a screen while entering the preset name “Velvet Club” in
location 10:
DPA-240A
1x2 WAY X-OVER
[ENTER] to Save
10: Velvet Club
DPA-240A
1x2 WAY X-OVER
Set Program Name
10: Velvet Club ?
