• MENU “A and B Output Channels Compressor/Limiter” [Access by pushing the
“LCOMP/RCOMP” buttons]
From the “Default Screen”, it is possible to access the “Equalizer’s Compressor” menu by pressing
the “LCOMP” or “RCOMP” button. Once pressed, the related blue “EDIT” LED will turn ON.
The Sub-Menus pages can now be scrolled through by rotating clockwise and counter-clockwise
the “NAV/PM1” encoder.
For parameter editing it is necessary to press ENTER and an arrow will appear on the left of the
screen “->”. Then use the “PM2” and “PM3” encoders for selecting and setting the parameter
values. On some parameters that have three independent values, you will also need to use the
“NAV/PM1” encoder, for example for the filter’s parameter setting.
Note: All parameter editing can be done using the “NAV/PM1”, “PM2”, and “PM3” encoders and the
current shown value of the selected option is AUTOMATICALLY loaded during the encoders’ use
and stored as the current value once leaving the page.
Limiter sub-menu - from this page it is possible to set the Equalizer’s Channels Limiter.
The following is an example screen for the Limiter page where the Attack Time of the Limiter is set
at 5ms, the Release Time is set at 0.2sec and the Limiter Active Threshold is set at +5dB:
Upon pushing ENTER, the Limiter’s parameters can be modified using the “NAV/PM1”, “PM2” and
“PM3” encoders for editing the Limiter’s Attack Time [A], Release Time [R] and Active Threshold.
Upon pushing ENTER, the above screen will change as follows:
The Attack Time [A] can be edited using the “NAV/PM1” encoder, the Release Time [R] the “PM2”
encoder and the Limiter Active Threshold the “PM3” encoder.
“Attack Time [A]”: the selectable range of the Limiter’s Attack Time is from 5ms to 200ms in steps
of 1ms - from 5ms to 20ms, 5ms - from 20ms to 30ms, 10ms - from 30ms to 100ms and 20ms - from
100ms to 200ms.
The Limiter’s Attack Time can be adjusted by rotating the “NAV/PM1” encoder.
“Release Time [R]”: the selectable range of the Limiter’s Release Time is from 0.1s to 3s in steps
of 0.1s and can be adjusted by rotating the “PM2” encoder.
“Limiter Active Threshold”: the selectable range of the Limiter’s Threshold is from +20dB
(Limiter not active) to -10.0dB in steps of 0.2 dB and can be adjusted by rotating the “PM3”
encoder.
Note1: Once the desired options have been selected using the 3 encoders, they are automatically
saved as current and stored in the DS-EQ230 system status once leaving the page.
Note2: To exit this page, push the “ESC” button.
Note3: The LED meters on top of the LCOMP and RCOMP buttons are indicating the Limter’s
activity, showing from top to down the output signal limitation in dBu.
