• Equalizer’s Channels LIN/RIN and Compressor/Limiter’s Channels
LCOMP/RCOMP Last Edited Parameter Return Function
Once you have escaped out of parameter editing within the individual Equalizer’s Channel or
Compressor’s Channel the DS-EQ230 will remember this last editing action on that Channel.
When you return for your next editing action pressing the EDIT button on that channel will
immediately return you to the screen related to this last editing action.
This function makes fine tuning or modifying easier when it is necessary to make a number of
adjustments to the same parameter in a short time sequence.
• Equalizer’s Channels and Compressor/Limiter’s Channels LINK Function
The DS-EQ230 is able to perform a unique LINK MODE between Equalizer’s Channels as well as a
link between Compressor’s Channels to enable quick and immediate editing (you cannot link
Equalizer’s to Compressor’s channels).
To link channels when editing, you will need to select a “Master” channel that will be the one to be
edited and have its parameters displayed on the LCD screen. You can then select and link the other
channel (Slave) that you wish to apply the same changes to.
To enter a link mode session, select the Master channel Edit mode, then link the Slave by pressing
their related Edit buttons.
Once Linked, the channels will be selected ready for adjustment when their “Blue” LED is lit in the
Editing mode.
Now the Slave channel will modify its parameters accordingly as you edit the Master channel.
All other existing parameters will stay the same within the Slave Channel unless edited by this link
with the Master channel.
Note: The LINK function is NOT a COPY function.
If we want to edit the Limiter of the Equalizer’s Channel A (named Left), we can enter the editing
mode of Compressor’s Channel A by pressing the related LCOMP Edit button and turning on the
Blue LED below the LCOMP LED meters. This assigns the “role” of Master and displays this
Channel’s parameters on the LCD:
Then press the Edit button of Compressor’s Channel B, turning ON its related “Blue” LED’s. Now
All parameters edited on Compressor’s Channel A, will also be applied to channel B.
If we want to remove the linked channel from the Link, press the related Edit button.
Exiting the editing of the Master channel during a Link session will automatically terminate that
session. The Link will also be automatically terminated if, during the editing of Compressor’s
Channels you jump across to begin editing an Equalizer’s Channel or vice versa.
DPA-240A
1x2 WAY X-OVER
DPA-240A
1x2 WAY X-OVER
DPA-240A
1x2 WAY X-OVER
OutputA Left Limiter
A: 5ms R: 0.2s +5.0dB
