• DS-EQ230 Technical Specifications
The DS-EQ230 Digital Graphic/Parametric Equalizer is based on a powerful analog and
digital DSP platform having the following specifications
Analog Input Signal: LIN/RIN Bal. Female XLR
Maximum Input Level: +20dBu
Analog Output Signal: LOUT/ROUT Bal. Male XLR
Maximum Output Level: +20dBu
Digital Processing (DSP): SAM3716, 24bits (data) x 96 bits (coeff.)
A/D Converters: AKM5392, 24bits
D/A Converters: AKM4396, 24bits
Sampling Frequency: 48kKz
S/PDIF Stereo Digital Input: 32kHz, 44.1kHz and 48kHz Sources Accepted
S/N: 110dBA
THD+N: 0.005%
Frequency Response (Bypass): 20Hz - 20Hz (+- 1dB)
Power Supply: Switching Power Supply
Remote Control: USB, RS485
Dimensions: 9.25" x 19" x 1.75" (234.95 x 482.6 x 44.45 mm)
Weight: 6.3lb (2.86kgs)
