87
Functions
(Initial screen)
Use the or
button to select the
menu screen.
Press the button.
Use the or
button to select the
function.
Press the button.
Calling the setup screen
* When the direct call button is set,
the setup screen is also called by the
following method:
MENU SELECT
DIRECT SEL
Press the and
button simulataneously.
Press the button set
at this function.
* Calling from menu screen
(Initial screen)
MENU
Channel 3 Position/CH3-POSI(Channel 3 system)
Use this function to set the servo position of the channel 3.
This setting is linked to transmitter knob (KNB). When the knob is assigned to an-
other function, set the channel 3 position with this screen.
Setup Item
RATE: Channel 3 posiion
Adjustment buttons
- Use the (+) and (-) buttons to make
adjustments.
- Press the (+) and (-) buttons simulta-
neously (approx. 1 sec) to return to
the initial screen.
Channel 3 adjustment
1 (Position adjustment)
Use the (+) and (-) buttons to adjust the channel
3 position.
- This position is linked with the knob (KNB).
2 When ending adjustment, return to the initial
screen by pressing the (END) button 3 times.
Channel 3 position
-100~0~+100%
Initial value: 0%
Channel 3 Position/CH3-POSI(Channel 3 system)
