Functions

Tilt mixing adjustment
(Preparation)
- Select setup item "MODE" and make the following ad-
justments.

1 (Function ON/OFF)

Set the function to the "ON" state by pressing the
(+) or (-) button.

"INH" : Function OFF
"ON"

: Function ON

2 (CH1>CH3 mixing amount adjustment)

Select setup item "CH1>3" by pressing the (UP)
button twice, and use the (+) and (-) buttons to
adjust the mixing amount.

"+" : Operate in same direction as steering
"-" : Operate in opposite direction of steering

3 (CH1>CH1 mixing amount adjustment)

Select setup item "CH3>1" by pressing the (DN)
button once, and use the (+) and (-) buttons to
adjust the mixing amount.

"+" : Operate in same direction as channel 3
"-" : Operate in opposite direction of channel 3

4 When ending adjustment, return to the initial

screen by pressing the (END) button 3 times.

Mixing amount
-100~+100
Initial value: +100

Function ON/OFF
INH, ON

Mixing amount
-100~+100
Initial value: -100

Tilt mixing/TILT MIX (Steering system/throttle system)
