83
Functions
(Initial screen)
Use the or
button to select the
menu screen.
Press the button.
Use the or
button to select the
function.
Press the button.
Calling the setup screen
* When the direct call button is set,
the setup screen is also called by the
following method:
MENU SELECT
DIRECT SEL
Press the and
button simulataneously.
Press the button set
at this function.
* Calling from menu screen
Use the or button to
select the setup item.
* blinks at the current
setup item.
(Initial screen)
MENU
Function select switch setup
1 (To select a function for SW1)
Press (UP) button or (DN) button to select
"SW1". Then, select one of the functions for
SW1 by pressing (+) or (-) button.
-
Refer to the previous page for abbreviations of functions.
2 (To change the operation mode of SW1)
Press (DN) button once to move the cursor to the
"NOR" or "ALT" message. Now, press (+) or (-)
button to select either "NOR" or "ALT".
3 (To select an arrange type for SW2)
Press (UP) button or (DN) button to select "AR-
RANGE". Then, select one of the three, "AR-
RANGE-1", "ARRANGE-2" and "ARRANGE-3"
by pressing (+) or (-) button.
-
Refer to the previous page for ARRANGE types.
4 (To select a function for SW2)
Press (UP) button or (DN) button to select
"SW2". Then, select one of the functions for SW2
by pressing (+) or (-) button.
-
Refer to the previous page for abbreviations of functions.
5 (To end setting)
Press (END) button three times to return to the
Initial Screen. (Press once in case of Direct
Mode.)
* Setup item shifts in function -> direc-
tion of operation order.
Function selection
Function select switch/FUNC-SW
Arrange selection
Switch position
Direction of operation setting (NOR/ALT)
