71
Functions
(Initial screen)
Use the or
button to select the
menu screen.
Press the button.
Use the or
button to select the
function.
Press the button.
Calling the setup screen
* When the direct call button is set,
the setup screen is also called by the
following method:
MENU SELECT
DIRECT SEL
Press the and
button simulataneously.
Press the button set
at this function.
* Calling from menu screen
Use the or button to
select the setup item.
* blinks at the current
setup item.
(Initial screen)
MENU
Subtrim/SUB-TRIM(All channel)
Use this function to adjust the neutral position of the steer-
ing, throttle and channel 3 servos.
Subtrim shifts the entire servo travel range in the set direc-
tion.
Use to adjust the neutral position
* Steering subtrim
* Throttle subtrim
* Channel 3 subtrim
Brake side operation stop method
(Preparation)
-Set the steering and throttle digital trims to the neutral
"0" position. Set CH3 to the center "0" position.
- Preselect setup channel "ST", "TH", or "CH3".
1 (Subtrim adjustment)
Use the (+) or (-) button to adjust the center.
(Each channel can be set similarly.)
2 When ending adjustment, return to the initial
screen by pressing the (END) button 3 times.
Subtrim
ST
: L100~R100
TH : B100~F100
CH3 : -100~+100
Initial value : 0
Subtrim/SUB-TRIM(All channel)
