38
Options 6
System Opt
Power Mng
4 Comm Opt
Options 6
4 System Opt
Power
Mng
Comm Opt
SYSTEM OPTION
System option enables user to configure the following areas:
• Date & Time Setting
• Date & Time Format
• Languages
• Advance Options
Reset Opts to restore all settings back to original factory settings
Del Attlogs to clear all attendance log stored in reader
Clear all Data to clear all user data (i.e user name, ID number)
Clr Admin Pri to clear administrator’s privilege
Show Score to show the quality of image captured during verification, the maximum is 50
Match Thr to configure sensitivity of the optical sensor for 1:N matching
1:1 Thr to configure sensitivity of optical sensor for 1:1 matching
COMMUNICATION OPTION
This is to configure communication settings of Q2 readers. User can
choose the type of communication (TCP/IP, RS232 or RS458). Improp-
er settings will cause connection to computer to fail.
Those options are:
Baud rate to adjust baud rate of connection with RS232 or RS485
Dev num the number of reader in an installed environment
IP Addr to configure the IP address of reader
Net speed to adjust the speed connection of Ethernet
Netmask to configure netmask to suit reader into local area network.
Gateway to configure gateway to suit reader into local area network.
Ethernet to enable or disable Ethernet as communication method
