Table 1 – EVCO ECK256J220S001 User Manual
Page 5
5
1 '96
PARAMETER CODE
DESCRIPTION
MIN.
MAX.
U.M.
ST. 1
ST. 2
(1)
PA
Password
-99
100
——
——
/
PROBE
/0
type of probe
10=TC “J”; 11=TC “K”
10
11
——
*
(1)
/1
calibration (measurement offset)
-10
+10
°
C
+2
/2
digital filter (response time)0=0s; 1=0,4s; 2=1,2s; 3=2,8s; 4=6s; 5=12,4s; 6=25,2s
0
6
——
3
r
TEMPERATURE CONTROL
r1
minimum available setpoint
0
+999
°
C
0
r2
maximum available setpoint
0
+999
°
C
+195
b
DEEP FRIER CONTROL
(2)
b0
auto-restart function
0=YES; 1=NO
0
1
——
0
b1
enable pre-heat from start
0=NO; 1=YES
0
1
——
1
b2
Melt threshold
0
+999
°
C
+100
b3
differential band for temperature inside range
+1
+25
°
C
+5
b4
time-out for temperature inside range
0
120
sec.
20
b5
pre-heat cycle time
0
120
sec.
40
b6
pre-heat on-time
0
100
%
15
(3)
b7
buzzer on-time
-1
120
sec.
5
P
P.I.D. CONTROL
PO
control band offset
-99
+99
°
C
-40
-35
PI
integral time constant
0
999
sec.
75
100
Pb
proportional band
+1
+250
°
C
35
Pc
P.I.D. cycle time
1
120
sec.
40
60
Pd
derivative time constant
0
250
sec.
25
35
A
ALARM
A0
alarm hysteresis (differential)
+1
+99
°
C
+1
A1
alarm setpoint
-99
+999
°
C
0
A3
alarm delay time at unit start up
0
999
min.
0
A4
alarm type
see TABLE 1
——
1
L
NETWORK CONNECTION
L1
unit address
1
15
——
1
L2
unit group
0
7
——
0
L3
link time-out
2
250
——
0
L4
baud rate 0=1200; 1=2400; 2=4800; 3=9600
0
3
baud
1
CONFIGURATION PARAMETERS
Note
(*) = it depends on input type; the parameter must be set according to hardware factory setting.
(1) = configuration parameter present at Level 1.
(2) = this parameter controls the device operation at switch on after a power supply failure during “START” status: if this parameter is set to 0,
the operation of the control unit depends on the duration of power supply failure (see section “OPERATION”); vice-versa, if the parameter
is set to 1, the control unit restarts in “START” status.
(3) = this parameter defines the buzzer signal duration when the Melt threshold or the operating setpoint has been reached: if it is set to 0 there
is no buzzer signal; vice-versa, if it is set to –1 the buzzer signal continues until it is manually switched off.
TABLE 1
parameter A4
alarm type
1
alarm disabled
2
low temperature (absolute) alarm
3
high temperature (absolute) alarm
4
low temperature (to setpoint reference) alarm
5
high temperature (to setpoint reference) alarm
6
low temperature (to setpoint reference) alarm with autom. calc. of new values and reset
7
high temperature (to setpoint reference) alarm with autom. calc. of new values and reset
