Evco S.p.A. c-pro 3 CLIMA sistema | User manual ver.1.0 | Code 115CP3CSE104
page 4 of 14
1 USER INTERFACE
1.1 Display and keyboard
The user interface is composed of a membrane keyboard with 6 keys with one-colour graphical LCD (black with white
LED back-lighting), with 128 x 64 pixel, which confers the instrument with large information capacity joined with user-
friendliness.
1.2 Navigation
There are 6 navigation and value editing keys present in the keyboard with the following meaning:
- (UP and DOWN) are used to scroll the parameters inside the pages and to modify the value once in
modification mode.
- (LEFT and RIGHT) used to scroll the pages of the main menu.
- (ESC) used to go back to previous screens.
- (ENTER) used to select the parameters to edit and to confirm the value once edited.
