cables up to 2.5 mm² (0.38 sq in, inputs).
Ambient temperature: from 0 to 55 °C (32 to 131 °F, 10 ... 90% of relative humidity
without condensate).
Power supply: 230 Vac, 50/60 Hz, 4 VA (standard) or 115 Vac, 50/60 Hz, 4 VA
(by request).
Alarm buzzer: included.
Measure inputs: 2 (top and floor probe) for “J” or “K” thermocouples.
Working range: from 0 to 700 °C (32 to 999 °F) for “J” thermocouple,
from 0 to 999 °C (32 to 999 °F) for “K” thermocouple.
Setpoint range: from 0 to 999 °C (0 to 999 °F).
Range of the timer for delayed starting: from 1 to 99 h.
Range of the cooking timer: from 1 to 99 min.
Resolution: 1 °F with unit of measure in Fahrenheit, 1 °C with unit of measure in
Celsius.
Display: two red LED 3-digit displays 13.2 mm (0.51 in) high, one red LED 2-digit
display 13.2 mm (0.51 in) high, output status indicators, indicators of the unit of meas-
ure of the temperature showed by the instrument.
Outputs: 6 relays: one 8 A @ 250 Vac relay for top heating group control (NO),
one 8 A @ 250 Vac relay for floor heating group control (NO), one 10 A @ 250 Vac relay
for steam generator control (NO), one 8 A @ 250 Vac relay for steam injection control
(NO), one 8 A @ 250 Vac relay for extractor control (NO), one 8 A @ 250 Vac relay for
chamber light control (NO); the maximum current allowed on terminal 21 and 26 is
10 A.
10 WORKING SETPOINT AND CONFIGURATION PARAMETERS
10.1 Working setpoint
LABEL MIN. MAX. U.M. DEF. WORKING SETPOINT
rA1 rA2 °C/°F (7) 0 top setpoint
rA1 rA2 °C/°F (7) 0 floor setpoint
10.2 First level parameters
LABEL MIN. MAX. U.M. DEF. PASSWORD
PA -90 100 --- 0 password
LABEL MIN. MAX. U.M. DEF. MEASURE INPUTS
/1 -10 10 °C/°F (7) 0 top and floor probe calibration
LABEL MIN. MAX. U.M. DEF. REGULATOR
rA0 -15 -1 °C/°F (7) -2 hysteresis (differential, it is relative to the top and the floor setpoint)
10.3 Second level parameters
LABEL MIN. MAX. U.M. DEF. MEASURE INPUTS
/0 10 11 --- 10 kind of probe (10 = “J” Tc, 11 = “K” Tc)
/1 -10 10 °C/°F (7) 0 top and floor probe calibration
/2 0 6 --- 3 probes reading speed (0 = fast, ... , 6 = slow)
/4 0 1 --- 0 display of non meaningful zeros (1 = YES)
/8 0 1 --- 1 unit of measure temperature (0 = Fahrenheit degree, 1 = Celsius degree)
LABEL MIN. MAX. U.M. DEF. REGULATOR
rA0 -15 -1 °C/°F (7) -2 hysteresis (differential, it is relative to the top and the floor setpoint)
rA1 0 rA2 °C/°F (7) 0 minimum value you can assign to the top and the floor setpoint
rA2 rA1 999 °C/°F (7) 300 maximum value you can assign to the top and the floor setpoint
LABEL MIN. MAX. U.M. DEF. STEAM INJECTION
tb0 1 255 s 1 minimum time between two steam injections in succession
tb1 1 255 ds (8) 10 minimum length of the steam injection
LABEL MIN. MAX. U.M. DEF. FIRST ALARM (it is related to the top temperature)
AA0 1 99 °C/°F (7) 2 hysteresis (differential, it is relative to AA1, it is important if AA4 ≠ 1)
AA1 -99 999 °C/°F (7) 0 first temperature alarm threshold (it is important if AA4 ≠ 1); look at AA4 as well
AA3 0 999 min 0 first temperature alarm exclusion time since you turn the instrument ON (it is important if
AA4 ≠ 1)
