Evco S.p.A. • Code 1049336E00 • page 7/8
18 WORK SET-POINT, POWER DISTRIBUTED AND CONFIGURATION PARAMETERS
18.1 Work set-point
MIN. MAX. U.M. 1 INPUT 2 INPUTS
r1 r2 °C/°F (1) 150 not visible
r1 r2 °C/°F (1) not visible 150
r7 r8 °C/°F (1) not visible 150
18.2 Power distributed
PARAM. MIN.
MAX. U.M. 1 INPUT 2 INPUTS
0 100 % 50 not visible
0 100 % 50 not visible
18.3 Configuration parameters
PARAM. MIN.
MAX. U.M. 1 INPUT 2 INPUTS
SP r1 r2 °C/°F (1) 150 not visible
SPS 0 999 °C/°F (1) 100 not visible
SP1 r1 r2 °C/°F (1) not visible 150
SP2 r7 r8 °C/°F (1) not visible 150
PARAM. MIN. MAX. U.M. 1 INPUT 2 INPUTS
Po1 0 100 % 50 not visible
Po2 0 100 % 50 not visible
PARAM. MIN. MAX. U.M. 1 INPUT 2 INPUTS
CA1 -25/-50 25/50 °C/°F (1) 0 0
CA2 -25/-50 25/50 °C/°F (1) not visible 0
P0 0 1 - - - - 0 0
P2 0 1 - - - - 0 0
P4 0 1 - - - - 0 not visible
P5 0 (3) - - - - 0 0
P6 0 (4) - - - - 2 2
PARAM. MIN. MAX. U.M. 1 INPUT 2 INPUTS
r0 1 99 °C/°F (1) 5 5
r1 0 r2 °C/°F (1) 50 50
r2 r1 999 °C/°F (1) 350 350
r6 1 99 °C/°F (1) not visible 5
r7 0 r8 °C/°F (1) not visible 50
r8 r7 999 °C/°F (1) not visible 350
r12 0 1 - - - - 0 0
r13 0 240 min 240 240
r14 0 1 - - - - 0 0
PARAM. MIN. MAX. U.M. 1 INPUT 2 INPUTS
t0 0 1 - - - - 0 0
t1 0 250 s 1 1
t2 1 250 ds (7) 10 10
t3 1 99 °C/°F (1) 5 not visible
t4 0 99 °C/°F (1) 50 not visible
PARAM. MIN. MAX. U.M. 1 INPUT 2 INPUTS
c0 0 2 - - - - 0 not visible
c1 1 999 s 80 80
c2 0 3 - - - - 1 not visible
c3 0 99 °C/°F (1) 10 not visible
c4 -1 120 s 15 15
c5 0 60 min 20 20
c6 0 60 min 20 20
c7 00:00 60:00 min:s 00:30 00:30
c8 0 1 - - - - 1 1
c9 0 120 s 10 10
c10 0 999 min 120 120
WORK SET-POINT
work set-point
top set-point
floor set-point
POWER DISTRIBUTED
power distributed to the top (percentage of c1); see also c0 and c1
power distributed to the floor (percentage of c1); see also c0 and c1
WORK SET-POINT
work set-point
steam set-point
top set-point
floor set-point
POWER DISTRIBUTED
power distributed to the top (percentage of c1); see also c0 and c1
power distributed to the floor (percentage of c1); see also c0 and c1
MEASUREMENT INPUTS
with 1 measurement input, chamber probe inset; with 2 measurement inputs, top probe offset
with 1 measurement input, steam probe inset; with 2 measurement inputs, floor probe offset
type of probe
0 = J
1 = K
temperature unit of measurement (2)
0 = °C
1 = °F
enabling the steam probe
1 = YES
quantity shown by the upper part of the display during the on state or during normal functioning
0 = with 1 measurement input, chamber temperature; with 2 measurement inputs, top temperature
1 = with 1 measurement input, work set-point; with 2 measurement inputs, top set-point
2 = temperature of the floor
3 = floor set-point
quantity shown by the lower part of the display during the on state or during normal functioning
0 = with 1 measurement input, chamber temperature; with 2 measurement inputs, top temperature
1 = with 1 measurement input, work set-point; with 2 measurement inputs, top set-point
2 = value of the cooking timer or its count if the timer is active
3 = day and real time
4 = temperature of the floor
5 = floor set-point
MAIN REGULATOR
with 1 measurement input, work set-point differential; with 2 measurement inputs, top set-point differential
with 1 measurement input, minimum work set-point; with 2 measurement inputs, top minimum set-point
with 1 measurement input, maximum work set-point; with 2 measurement inputs, top maximum set-point
floor set-point differential
minimum floor set-point
maximum floor set-point
restraint between the top output and the cooking timer
1 = YES - the top output remains off if the cooking timer count is not in progress
duration of a power supply cut-off duration that occurs during a cooking timer count exceeding which the count is interrupted (5)
restraint between the floor output and the cooking timer
1 = YES - the floor output remains off if the cooking timer count is not in progress
STEAM INJECTION
steam injection functioning mode
0 = pressing the
key causes the injection of steam for the time established with parameter t2 or for the entire duration that the key is pressed. The
parameter t1 establishes the minimum time that can pass between the two successive injections
1 = pressing the key enables automatic injection of the steam in cyclical mode (parameter t2 establishes the switch-on duration of the injector and
parameter t1 establishes switch-off duration)
se t0 = 0, minimum time that passes between two successive injections
se t0 = 1, injector switch-off duration
se t0 = 0, minimum injection duration
se t0 = 1, injector switch-on duration
steam set-point differential
temperature of the steam below which, once the steam set-point has been reached, the steam injection is no longer available (relative to the steam set-
point i.e. “steam set-point - t4”) (6)
VARIOUS
restraint between the power distributed to the top and power distributed to the floor
0 = no restraint
1 = the modification of the power supplied to an output automatically causes the supply of the maximum power to the other
2 = the modification of the power supplied to an output causes an automatic adaptation of the power supplied to the other such to guarantee that the
sum of the two percentages is always 100
with 1 measurement input, cycle time for the top output and floor output switch-on, see also Po1 and Po2
with 2 measurement inputs, cycle time for the top output and floor output switch-on, when economy function is in progress (8)
event that causes the activation of the rapid heating function
0 = function cannot be activated
1 = press
for 1s (make sure that the instrument is in the on state, that no procedure is in progress and the economy function is not is progress)
2 = to pass from the stand-by state (or the programmed switch-on state) to the on state
3 = press
for 1s (make sure that the instrument is in the on state, that no procedure is in progress and the economy function is not is progress) or
pass from the stand-by state (or the programmed switch-on state) to the on state.
temperature of the chamber over which the rapid heating function is interrupted (relative to the work set-point i.e. “work set-point - c3”)
duration of buzzer activation and of the acoustic output on conclusion of the cooking timer count; see also c9 (9) (10)
-1= the buzzer and the acoustic output must be deactivated in manual mode by pressing a key
time that passes between the activation of the airhole and the conclusion of the cooking timer count, see also c6
duration of the activation of the airhole at conclusion of the cooking timer count, see also c5
duration of the activation of the airhole in manual mode
showing the real time in the lower part of the display during the stand-by state
1 = YES
time that passes between the activation of the buzzer and the acoustic output and the conclusion of the cooking timer count, see also c4
maximum duration of the economy function (11)
