INSTALLATION

For a proper installation take note of the attached indications.
Be sure that the conditions of use (environment temperature, humidity, power supply voltage, etc ...) are inside the indicated limits.
Do not overload the relay outputs over the indicated limits.
It is necessary to give the outputs the suitable protection against the short circuits and overloads.

Electrical connections

Example of typical application
