12
CONFIGURATION PARAMETERS (2/2)
NOTE CODE PARAMETER DESCRIPTION MIN. MAX. U.M. STAND.
(8) u1 door-switch deactivate evaporator fans output 0=NO; 1=YES 0 1 --- 1
(8) u2 door-switch input polarity 0=NO; 1=NC 0 1 --- 0
(8) u3 locking input polarity 0=NO; 1=NC 0 1 --- 0
u4 disabling time of the locking input on alarm 0 999 sec. 5
A TEMPERATURE ALARM REGULATOR
A0 hysteresis (differential, ref. to the cabinet probe) +1 +15 ° C +2
(9) A1 lower temperature alarm set relative to the cold-storing set (ref. to the cabinet probe) -99 0 ° C 0
(9) A2 upper temperature alarm set relative to the cold-storing set (ref. to the cabinet probe) 0 +99 ° C 0
(9) A3 lower temperature alarm set relative to the very cold-storing set (ref. to the cabinet probe) -99 0 ° C 0
(9) A4 upper temperature alarm set relative to the very cold-storing set (ref. to the cabinet probe) 0 +99 ° C 0
A5 disabling time of the alarm temperature from the beginning of the cold-storing 0 255 min. 30
A6 disabling time of the alarm temperature 0 255 min. 0
L RESERVED
L1 reserved --- --- --- ---
L2 reserved --- --- --- ---
L3 reserved --- --- --- ---
L4 reserved --- --- --- ---
QUICK-COOLING/FREEZING FOR TIME
NOTE CODE PARAMETER DESCRIPTION MIN. MAX. U.M. STAND.
quick-cooling/freezing for time length 0 999 min. 90
NOTES
(1) = configuration parameters present on Level 1.
(2) = reading parameter (it can not be changed).
(3) = it establishes the time between the start of an automatic or manual defrost and the start of the following automatic one and, during
a cycle/phase of cold-storing, the time between the start of the cycle/phase of cold-storing and the start of the first automatic defrost;
if the parameter has value 0 the automatic defrost will never be activated, excepting the parameter d4.
(4) = it establishes the kind of defrost that the instrument must manage, as indicated:
0=resistances (during the defrost compressor output deactivated and defrost output activated),
1=hot gas (during the defrost compressor and defrost outputs activated),
2=air (during the defrost evaporator fans and defrost outputs activated).
(5) = it establishes if to subjugate the compressor output to the disabling time established with the parameters C0, C1 and C2 or to clear
this times when a defrost is requested, as indicated:
0=the disabling time are observed,
1=the disabling time are cleared.
(6) = it establishes the measure unit for the parameters d0, d3, d7 and F5, as indicated:
0=the measure unit for the parameter d0 is hours, the measure unit for the parameters d3, d7 and F5 is minutes,
1=the measure unit for the parameter d0 is minutes, the measure unit for the parameters d3, d7 and F5 is seconds.
(7) = it establishes the output activity, as indicated:
0=the output activity depends from the temperature read by the evaporator probe and from the parameters F1 and F2, excepting
the parameters d7, F3, F4 and F5,
1=the output is continuously activated, excepting the parameters d7, F3, F4 and F5.
(8) = set to 0 this parameter if the digital inputs are not used.
(9) = if the parameter has value 0 the temperature alarm is disabled.
