EVCO EVK404N9 User Manual

Page 5

Evco S.p.A. • Code 104K404E114 • page 5/8

WORK SET-POINT AND CONFIGURATION PARAMETERS

12.1 Work set-point

MIN.

MAX. U. M.

CFG = 0 CFG = 1 CFG = 2 CFG = 3 CFG = 4 CFG = 5 CFG = 6 CFG = 7 CFG = 8 CFG = 9

°C/°F (1)

20.0

°C/°F (1)

40.0

12.2 Configuration parameters
PAR.

MIN.

MAX. U. M.

CFG = 0 CFG = 1 CFG = 2 CFG = 3 CFG = 4 CFG = 5 CFG = 6 CFG = 7 CFG = 8 CFG = 9

SP1

°C/°F (1)

20.0

SP2

°C/°F (1)

40.0

PAR.

MIN.

MAX. U. M.

CFG = 0 CFG = 1 CFG = 2 CFG = 3 CFG = 4 CFG = 5 CFG = 6 CFG = 7 CFG = 8 CFG = 9

CA1

-25.0

25.0

°C/°F (1)

0.0

CA2

-25.0 25.0

°C/°F (3)

0.0

not avail. not avail. not avail. not avail.

0.0

P01

- - - -

P02

- - - -

not avail. not avail. not avail. not avail.

- - - -

P21

- - - -

P22

- - - -

not avail. not avail. not avail. not avail.

-199.0 9990 points

0.0

-199.0 9990 points

100.0 100.0

100.0

- - - -

not avail. not avail. not avail. not avail.

- - - -

not avail. not avail. not avail. not avail.

250

WORK SET-POINT
work set-point SP1
work set-point SP2 (2)

WORK SET-POINT
work set-point SP1
work set-point SP2 (2)
MEASURE INPUTS
probe 1 offset
probe 2 offset
probe 1 type
0 = PTC
1 = NTC
2 = Pt 1000
3 = 4-20 mA; see also P3 and P4
4 = 0-10 V; see also P3 and P4
probe 2 type
0 = PTC
1 = NTC
2 = Pt 1000
3 = 4-20 mA; see also P10 and P11
4 = 0-10 V; see also P10 and P11
if P01 and/or P02 = 0, 1 or 2, decimal point (for the magnitude displayed during
normal operation)
1 = YES
if P01 and/or P02 = 3 or 4, position of the decimal point
0 = no decimal point
1 = on the tens character
temperature unit of measurement of probe 1 (affecting only degree Celsius LED and
degree Fahrenheit LED if P01 =3 or 4) (4) (5)
0 = °C
1 = °F
2 = the degree Celsius LED and the degree Fahrenheit LED remain off
temperature unit of measurement of probe 2 (affecting only degree Celsius LED and
degree Fahrenheit LED if P02 =3 or 4) (4) (6)
0 = °C
1 = °F
2 = the degree Celsius LED and the degree Fahrenheit LED remain off
probe 1 transducer minimum calibration value (only if P01 = 3 or 4)
probe 1 transducer maximum calibration value (only if P01 = 3 or 4)
magnitude displayed during normal operation
0 = magnitude detected by probe 1
1 = magnitude detected by probe 2
magnitude displayed by the EVT100 remote indicator
0 = magnitude detected by probe 1
1 = magnitude detected by probe 2
delay displaying magnitude variation detected by the probes

iSd2

External alarm with manual restore from digital input 2
Solutions:
• check the causes of input activation
• see parameters i5 and i6
• wait for the cause of the alarm to disappear and then

press the

and

keys for 1 s

Main consequences:
• the relays used for regulation will be forced to the state

established with parameter i11

• if parameter CFG is set at 3, the relays signalling the alarms

and errors will be switched on

When the cause of the alarm disappears, the device restores normal
operation, except for the following alarms:
• the external alarm with manual restore from digital input 1 (code

“iSd1”)

• the external alarm with manual restore from digital input 2 (code

“iSd2”)

which require the cause of the alarm to disappear and successively the
keys

and

to be pressed for 1 s.

ERRORS

10.1

Errors

CODE MEANING

Pr1

Probe 1 error
Solutions:
• see parameter P01
• check the integrity of the probe
• check the device-probe connection
• check the magnitude detected by the probe
Main consequences:
• the work Program function cannot be activated
• the work program will be interrupted if it is in progress
• the relays used for regulation will be forced to the state

established with parameter C4

• if parameter CFG is set at 3, the relays signalling the alarms

and errors will be switched on

Pr2

Probe 2 error
Solutions:
• see parameter P02
• check the integrity of the probe
• check the device-probe connection
• check the magnitude detected by the probe
Main consequences:
• if parameter P9 is set at values different to 0 (or if the CFG

parameter is set at 8 or 9), the device will function as if the
parameter is set at 0

• if parameter CFG is set at 3, the relays signalling the alarms

and errors will be switched on

• If the CFG parameter is set at 8, the relays used for

adjustment will be forced to the state established with
parameter C5

When the cause of the alarm disappears, the device restores normal
operation.
11

TECHNICAL DATA

11.1

Technical data

Container: grey self-extinguishing.
Front panel protection rating: IP 65.
Connections: screw terminal boards (power supply and outputs),
removable terminal board (inputs), 6-pole connector (serial port on
request), removable terminal board (at the remote indictor, on request);
removable spring terminal board (power supply and outputs) on
request.
Temperature of use: from 0 to 55 °C (from 32 to 131 °F,
10 ... 90% relative humidity without condensate).
Power supply: 12 VAC/DC (or 12-24 VAC/DC), 50/60 Hz, 3.5 VA
(approximate) or 115 ... 230 VAC, 50/60 Hz, 5 VA (approximate).
Alarm buzzer: on request.
Measure input: 2 (probe 1 and probe 2) for PTC/NTC probes,
Pt 1000 2 wires, 4-20 mA and 0-10 V transducers (universal
measure input).
Digital inputs: 2 (digital input 1 and digital input 2) for NO/NC
contact (potential-free contact, 5 V 1 mA).
Field of measurement: from -50 to 150 °C (from -50 to 300 °F) for
PTC probe, from -40 to 105 °C (from -40 to 220 °F) for NTC probe,
from -100 to 150 °C (from -145 to 300 °F) for Pt 1000 probe.
Resolution: 0,1 °C/1 °C/0,1 °F/1 °F.

Digital outputs: 4 relays:

• relay K1: 16 A res. @ 250 VCA (changeover switch)
• relay K2: 8 A res. @ 250 VCA (changeover switch)
• relay K3: 8 A res. @ 250 VCA (NO contact)
• relay K4: 8 A res. @ 250 VCA (changeover switch).

The maximum current accepted on relay 1 is 10 A.
Communication ports:

2 ports:
• TTL serial port for communication with

the EVKEY programming key, with the
Parameters Manager set-up software
(via a serial interface, with MODBUS
communication protocol) or for that
for monitoring or supervision of RICS
plants (via a serial interface, with
MODBUS communication protocol);
on request

• communication port with EVT100

remote indicator, on request.

PT • 35/12
