Comtrol IO-Link Master EIP-4 User Manual
Page 89
IO-Link Master EtherNet/IP Reference Manual: 2000589 Rev. A
Chapter 6. ControlLogix Family - Example PLC Programs - 89
Configure the Ethernet Module
8.
Enter IOLinkMstr for the Path for all MSG instructions in all four subroutines.
9.
Save the RSLogix5000 program.
10. Download to the PLC.
11. Start the PLC.
12. Click MainRoutine and review the RSLogix 5000 screen.
