IO-Link Master EtherNet/IP Reference Manual: 2000589 Rev. A Chapter 3. EtherNet/IP CIP Object Definitions - 53
Instance Attributes
3 Configuration Control DWORD
Interface control Flags:
0 = The device shall use
statically-assigned IP
configuration values.
2 = The device shall obtain its
interface configuration values
via DHCP.
Set/Get
4
Physical Link Object
Structure of:
Path Size
Path
UINT
Array of USINT
2
[0]=20 hex
[1]=F6 hex
[2]=24 hex
[3]=01 hex
Get
5
Interface Configuration
Structure of:
IP Address
Network Mask
Gateway Address
Name Server
Name Server 2
Domain Name Length
Domain Name
UDINT
UDINT
UDINT
UDINT
UDINT
UINT
STRING
Set/Get
6
Host Name
Structure of:
Host Name Length
Host Name String
UINT
STRING
0 to 15 Set/Get
8
TTL (Time-to-Live)
value for IP multicast
packets.
USINT 1 to 255 Set/Get
9
IP Multicast Address
Configuration
Struct of:
USINT - Alloc
Control
USINT -
Reserved
UINT - Num
Mcast
UDINT - Start
Mcast Address
Alloc Control:
0 = Default Algorithm
1 = Configuration
Num Mcast:
1 to 32
Start Mcast Address:
239.192.1.0 to
239.255.255.255
Set/Get
Attribute ID Name Data Type Data Value(s) Access Rule
