IO-Link Master EtherNet/IP Reference Manual: 2000589 Rev. A Chapter 3. EtherNet/IP CIP Object Definitions - 55
Instance Attributes
3.10.2. Instance Attributes
This table displays the Instance Attributes for the Ethernet Link Object (F6 hex - 1 Instance).
3.10.3. Common Services
This table displays the Common Services for the Ethernet Link Object (F6 hex - 1 Instance)
Attribute ID Name Data Type Data Value(s) Access Rule
1
Interface speed
(Current operational
speed)
UDINT
10=10 Mbit
100=100 Mbit
Get
2
Interface Flags
(Current operational
status)
DWORD
Bit 0 =link status
(0=inactive)
(1=active)
Bit 1=Half/Full Duplex
(0=half duplex)
(2=full duplex)
Bits 2-4:
00 = negotiation in progress
01 = negotiation failed
02 = negotiation failed speed OK
03 = negotiation success
Get
3 Physical Address
Array of 6
USINT
MAC Address Get
7 Interface Type USINT 2 = Twisted Pair Get
8 Interface State USINT
1 = Interface is enabled and
operational
Get
9 Admin State USINT 1 = Interface enabled Get
10 Interface Label
USINT16
Array of
USINT
Length = 1 to 64
ASCII characters
“xxx.xxx.xxx.xxx” format>
Get
Service Code Implemented in Class Implemented in Instance Service Name
01 hex Yes Yes Get_Attribute_All
0E hex Yes Yes Get_Attribute_Single
