TOSHIBA
6F8A0,8,0,2
I I i !
{ i I I
Notes:
Removing core coating for cable, be careful not to scratch and not to cut off cable and
shield.
Untying shields from cables as shown in Figure 5.4.
a .Open shield by tools like tweezers.
shield
b
.Pull the cable from shield.
cable
c .Stretch out shield.
Figure 5.4 Untying shields from cables
-
2 3
-
