5.1 Cables
(1) Standard cable
The standard cable shown in Figure 5.1 is connected when shipped.
The cable length can be ordered (option).
Table 5.1 Cables
Name
Cable type
Length
Nominal
cross-sectional area
Overall
diameter
Excitation
cable
Three-core chloroprene
cabtyre cable
5m
0.5 mm^
6 to 8 mm
Input signal
cable
Two-core sheathed
chloroprene cabtyre cable
5m
0.3 mm2
6 to 8 mm
(2) Elongate cable longer than 5m
By using scotch cast, the cable shown in Figure 5.2 can be connected with standard cable
(5m).
Table 5.2 Cables
Name
Cable type
Nominal
cross-sectional area
Overall diameter
Excitation
cable
Three-core chloroprene cabtyre
cable
2 mm2
11 to 13 mm
Input signal
cable
Two-core sheathed chloroprene
cabtyre cable
0.75 mm2
11 to 13 mm
-
