8. Preset Commands
The dome camera can set and perform various preset commands. The following
table lists the preset number and whether is can be set (SET) or performed (GO).
Presets 1 -32 and 35-66 are user presets. Please refer to your model's instructions
for information on inputting preset commands.
Preset Number Function
1-32 SET/GO Preset position 1-32
33 GO Flip
34 GO Home (return to 0 pan position)
35-66 SET/GO
Preset position 35-66
70 GO Begin Auto patrol
71 GO
Backlight compensation ON
72 GO Backlight compensation OFF
73 GO One push WB
74 GO One push trigger AF
75 GO Software version Display
76 GO P/T Initialize
83 SET Privacy Zone Setup menu mode
88 GO IR Cut filter ON
89 GO IR Cut filter OFF
90 SET Set manual left limit stop
91 SET Set manual Right limit stop
92 SET Set Scan Left Limit Stop
93 SET Set Scan Right Limit Stop
95 SET Enter Menu Mode
96 GO Stop Scan
97 GO Begin Random Scan
98 GO Begin Frame Scan
99 GO Begin Auto-scan
8.1 PROGRAMMING PRESETS
Programming presets varies with the model controller being used. Several controllers
are listed below. Please refer to your model's instructions for information on inputting
preset commands.
JK-UC1
Input the desired preset using the numeric keypad.
Press the SHIFT key.
The LED will light up.
Press the PRESET key.
KBD200/300/300V direct
Input the desired preset number using the numeric keypad.
Hold down the PRESET button for 5 seconds to set the preset.
- 2 6 -
