ROl-1102'l
Function Keys
Except for the [CODE] key, each of the function keys corresponds to the identical key installed
on the ECR keyboard as to the function in programming operations. {[CLEAR] = [C])
The [CODE] key cannot be used for the MA-1600 series ECRs.
Operation Examples
To set the Menu Item name “COFFEE" for Dept. 2:
ON ECR KEYBOARD ONLY
403 m 415 [#1
406f#l
3 [@ff=OR] [DEPT 2]
—
[ST] [AT/TL]
406f#l
405r#l
405t#l
FEE
USING TKB-1 KEYBOARD
3 l@/FOR] [DEPT 2] C O F F E E [ST] [AT/TL]
I___________________ iJ________________________ I
on ECR
on TKB-1
a@^OR], [ST], and [AT/TL] may be operated on ECR or on TKB-1. Code entries
such as “3” in the above example must be entered on ECR.)
The “One Double-size Declaration” (by depression [@/FOR] once prior to the required character) and
the “All Double-size Declaration" (by depressing [@/FORJ twice before the entire descriptor) are the
same as in setting characters on the ECR keyboard.
Any characters not listed on the TKB-1 keyboard may be entered by the code entry method on the
ECR keyboard, (the characters even listed on the TKB-1 keyboard may be entered as well by that
method).
- 39 -
