FoUow one of the steps below to connect an indoor or outdoor antenna to your TV (only if you do not have a
cable-TV system). You can connect the antenna to either
ANTA
or
ANT B
as explained on page 25. _______ ___________
A
If the antenna cable coming from your home antenna is a 75-ohm round coaxid cable that carries only VH^(ch^s 2-13)
only UHF (channels 14-69), or VHP and UHF channels, connect it to your set like this: ---------------
Incoming
Cable
From --------- ►
Home
Antenna
VHF or UHF Only
or
VHFAJHF Combination
BACK
OF TV
-OR-
B
■|f the mtenn. cable coming from your home m.enna is a 30i>r,hm flat twin le^ tlM carries only VHF <=h™^l 3)
only UHF (channels 14-69), or VHF and UHF channels, connect it to your set like this:
Incoming
Cable
From
Home
Antenna
3 :
VHF or UHF Only
Qf Antenna Adapter*
VHFAJHF Combination (such as RCA #193983)
Push on
ANTA
1 )
ANTB
%
CONVERTEn
BACK
OF TV
-OR-
If the antenna cables coming from your home antenna(s) are a 75-ohm round coaxial cable that carries VHF (channels 2-13)
and a 300-ohm flat twin-lead cable for UHF (channels 14-69), connect them to your set like this:
CABlffANTENNA
Incoming g|^p
Cables
From---------► and
Home
Antenna(s) VHF
--------
Push on
Antenna Mixer*
\ (such as RCA #197551)
-OR-
ANTA
BACK
OF TV
D
If Ihe antenna wires coming from your home antennafs) are two 3p0-ahm flat twin-lead cables as shown here, connect them
to your set like this:
CABLE/ANTENNA
Incoming
Cables
UHF
Home ----------------
Antenna(s) VHF
-
Push on
Antenna Mixer*
(such as RCA #193984)
Note: Be sure to connect the UHF antenna cable to the UHF screws on the Antenna
Mixer and the VHF antenna cable to the screws marked VHF.
BACK
OF TV
♦ Optional accessories are available from most dealers or electronics supply stores.
