Preparing for surround sound
lOeOVR [En/K
Adjust the volume levels of each speaker.
Listen to the test tone and adjust the volume level of each speaker so that they all produce the test tone at the same volume level
O
Select the test tone type.
AUTO ; The test tone switches between each speaker in regular intervals.
MANUAL : The test tone only comes from the selected speaker (displayed in blue).
OFF : Stops the test tone.
© Adjust the Volume level of each speaker.
X
Listen to the test tone and select the speaker you want to adjust.
• The selected speaker icon turns blue and the speaker name and level appear (at the bottor." of
the screen) to show that it can be adjusted.
X Listen to the test tone and adjust the volume level of the speaker (±10 dB) using the
TUNING/SKIP keys on the remote control.
TUNING/SKIP - : Lowers the volumeTUNING/SKIP + : Raises the volume
• Adjust the subwoofer as you desire.
© Continue to the SP.DIST (speaker distance) screen.
Enter the speaker distance.
Enter the distance from your listening position to the front (left or right), center, and rear (left or right) speakers, if both front (or
rear) speakers are not the same distance from the listening position, enter the distance to the closest speaker.
SETUP
SP.SICT I spm I sp.nBr irw
PnH H S!
SPEAKER
DISTANCE
10ft 3.0m
FRONT
;BURR.J;
o
O
Select the speaker.
The speaker name turns blue. An arrow icon appears to indicate the selected speaker.
© Enter the speaker distance.
Use TUNING/SKIP on the remote control to select the appropriate distance.
The distance is adjustable from O.Ometers (0 feet) to 9.0meters (30 feet) in 0.3meter (1 foot)
steps.
© Continue to the IN LVL (input level) screen.
Adjust the audio input level of the connected components.
Tne LEVEL INDICATOR lights during playback if the signal being input from an analog source is too large. If this occurs, use this
screen to attenuate the input level for that source.
SETUP
sp.strr I SP.IVI I spjisT I mvf
INPUT LEVEL
SELECTOR'illK
LEVEL
o
©
O
Select the input.
I Use TUNING/SKIP on the remote control to select the desired input.
, 2
Move the pointer downward.
© Select an input level.
The input level is adjustable in 3 levels. Use TUNING/SKIP on the remote control to select the
smallest level required to extinguish the LEVEL INDICATOR (normally, set to 0 dB).
0 dB -3 dB -6 dB
• Input level adjustment is not possible when using the ADAPTOR jacks.
© Press the SETUP key on the remote to turn off the on-screen display.
O Press either VIDEO, AUDIO, or TV key on the remote to cancel the OSD
remote control mode.
This completes the surround setup.
