Setting up ttie system
10B0VR (En/Kj
12 Connecting the system control
'b
3
3
J>
Connecting system control cords after connecting a KENWOOD audio component system lets you take advantage of
convenient system control operations.
There are two KENWOOD system control modes. Make connections according to the groups of terminal symbols shown
below.
ZXS.8 Mode : lets you combine IXS_’, ySB, and 1X7. terminals
ELIB Mode : for SLIB terminals only
This unit IS compatible with both IXS8I and 1SL16] modes. It comes from the factory set to the (SL161 mode. To switch to the [XS8] mode, follow
the instructions In "SWITCHING FROM [SL16I TO |XS8]" below.
EXAMPLE: [XS8] mode connections
The underlined portion represents the setting of the system control mode.
EXAMPLE: [SL16] mode connections
The underlined portion represents the setting of the system control mode.
[SL16] IXS81
[SL16]
[SL16] [XS] rXS81 [XR]
[SL16] [XS] [XS8]
[XS]
SYSTEM
CONTROL
cord
[SL161 [XS8]
[SL161
[SL161 [XS] [XS8] [XR]
[SL161 [XS] [XS8]
[XS]
SYSTEM
CONTROL
cord
■ In order to take advantage of the system control operations, the components must be connected to the correct jacks. To use a CD player it must
be connected to the CD jacks. To use a cassette deck (or MD recorder) it must be connected to the TAPE/MD jacks. When using more than one
CD player (etc.) only the one connected to the specified jacks may be connected for system control,
• Some CD players and cassette decks are not compatible with the ISL16] system control mode. Be sure to use the [XS8] system control mode
when making system connections with equipment that is not ISL16I compatible.
• Some MD players are not system control compatible. You cannot make system control connections to this kind of equipment.
[SL16I equipment cannot be combined with IXR], |XS], and (XS8) equipment for system operations. If your
equipment consists of this kind of combination, please do not connect any system control cords. Even without
system control cords, normal operations can be carried out without effecting performance.
, I
Do not connect system control cords to any components other than those specified by KENWOOD. It may
cause a ntalfunction and damage your equipment.
Be sure the system control plugs are inserted all the way in to the system control terminals.
:'t=3
SYSTEM CONTROL OPERATIONS
Remote Control
0 -. C'pe'a!‘?' **vs urn! witn the system remote supplied with the
Automatic Operation {except [XR] equipment)
Vv Vr,.. s:a'' OinvoacK from a source component, the input selector
T
:cnc-s to that component automatically
Synchronized Recording (except iXR] equipment)
we*.- .. ’ cf'm-'7c record'ng with the start of playbacK when
n'-com ' Cw r.'J or analoo aiscs
SWITCHING FR0M[SL16] TO [XS8]
You can easily change the system control mode by adjusting the
position of the SYSTEM CONTROL switch on the rear panel.
Do this operation after completing all connections.
ForiSLiei SL 16 XS 8 Forixsei
in
• This operation will not effect items stored in the memory.
• After switching the system control mode, turn the power off and
then on once to confirm the new setting.
Registering setup codes for KENWOOD audio components
• Once yo.. finish maning the system connections, be sure to register the appropriate setup code for each component. -ulE
’ h yoL, O v-."' 'emote control laole KENWOOD audio components that are not compatible with system control (or cannot be combined with your other
system control components), registering the setup code enables you to control those components using the remote control supplied with this
unit iwitnout connecting system control cords). To register setup codes for your remote controllable KENWOOD audio components, see
■Registering setup codes for other components",
